Exporter from China of solid carbide ball nose for aluminum-two flute 1-8mm for Copper and aluminum products processing advertising plaque
Description
| Place of Origin: | CHINA |
| Brand Name: | KONSOND |
| Size: | Φ1--Φ8mm Or can be customized |
- Specification
- Competitive Advantage
| Minimum Order Quantity: | 1pc |
| Price: | Based on different sizes, material and so on |
| Packaging Details: | carton |
| Delivery Time: | Within One month |
| Payment Terms: | TT 100% invoice value |
| Supply Ability: | 100 pcs/day |
Description:
High speed cutters for machining aluminum sheet and block material. These tools are
optimized for use on high- speed CNC mills, high speed machining centers and CNC routers.
Applications
It is used for Aluminum plate and single/ multi sheet aluminum.
For the sizes can be customized.
Specifications
Solid Carbide Ball Nose For Aluminum - Two Flute
UNIT: MM
| R(Radius) | D | D | B | S |
| 0.5R | 1 | 2 | 4 | 50 |
| 0.75R | 1.5 | 3 | 4 | 50 |
| 1R | 2 | 4 | 4 | 50 |
| 1.25R | 2.5 | 5 | 4 | 50 |
| 1.5R | 3 | 6 | 4 | 50 |
| 1.75R | 3.5 | 7 | 4 | 50 |
| 2R | 4 | 8 | 4 | 50 |
| 2.25R | 4.5 | 9 | 6 | 50 |
| 2.5R | 5 | 10 | 6 | 50 |
| 2.75R | 5.5 | 11 | 6 | 50 |
| 3R | 6 | 12 | 6 | 50 |
| 4R | 8 | 16 | 8 | 60 |
